Flat Panel Detector IRAY Venu 1717VX
€ 9.900,00
Venu 1717XV is a 17 × 17 inch tethered flat panel detector for digital X-ray imaging, designed for veterinary DR systems. It features amorphous silicon detector technology with a CsI scintillator, a 2912 × 2912 pixel matrix, and 16-bit A/D conversion, delivering high-quality images at a low radiation dose. With a 139 µm pixel pitch, 3.6 lp/mm spatial resolution, Ethernet interface, and fast image acquisition (3 s preview / 5 s full image), the Venu 1717XV ensures an efficient and reliable imaging workflow for both new and retrofit X-ray systems.
Venu 1717XV – 17 × 17 Inch Tethered Flat Panel Detector for Digital X-ray
The Venu 1717XV is a high-performance 17 × 17 inch tethered flat panel detector for digital X-ray imaging, designed specifically for the demanding needs of radiography. Utilizing advanced CsI scintillator technology, the detector significantly reduces radiation dose while delivering outstanding image quality.
Its fast imaging workflow allows doctors and operators to complete examinations efficiently, making it ideal for both new DR systems and retrofit digital X-ray solutions.
Key Benefits of the Venu 1717XV Digital X-ray Detector
- High-quality digital X-ray imaging
16-bit A/D conversion and 3.6 lp/mm spatial resolution ensure sharp, detailed images. - Low radiation dose
CsI scintillator technology improves X-ray absorption and reduces exposure. - Fast imaging workflow
Preview images available in approximately 3 seconds and full images in about 5 seconds. - Multiple trigger modes
Supports AED, preparation, and software triggering for flexible integration. - Reliable and robust design
Built for daily use in veterinary clinics and animal hospitals.
Applications
- Medical digital radiography (DR) systems
- Animal clinics and veterinary hospitals
- Retrofit upgrades of existing X-ray systems
- General Medical diagnostic imaging
Technical Specifications – Venu 1717XV
- Detector Technology: Amorphous Silicon
- Scintillator: CsI
- Active Area: 405 × 405 mm
- Pixel Matrix: 2912 × 2912
- Pixel Pitch: 139 µm
- Spatial Resolution: 3.6 lp/mm
- A/D Conversion: 16 bit
- Preview Image Time: ~3 s
- Full Image Time: ~5 s
- Data Interface: Ethernet
- Trigger Modes: AED / Preparation / Software
- Power Consumption: 25 W
- Dimensions: 460 × 460 × 15 mm
- Weight: approx. 4 kg
Operating Conditions:
- Temperature: 5–35 °C
- Humidity: 30–80 % RH (non-condensing)
Storage & Transport Conditions:
- Temperature: −10–55 °C
- Humidity: 10–90 % RH (non-condensing)
Conclusion
The Venu 1717XV flat panel detector is a reliable and future-proof solution for digital X-ray imaging in Medicine. Combining excellent image quality, low radiation dose, and fast workflow efficiency, it supports accurate diagnostics and optimized clinical operations.
